RPLC Series Single Cell Round Platforms
- Functions with an approved aluminum “single point” load cell according to OIML R60 standards with protection against dust and water splashes according to IP65 standards (350 Ohm input resistance)
- Anodized blue aluminum structure with adjustable resting feet and level
- Stainless steel plate
- 15 VDC power supply
- Shielded 1,5 m connection cable with connectors for connection to the indicator.
Painted Steel. Load cell in Aluminium. IP65 protection rating.
Precision class C3, C3MR.
Small capacity electronic round platforms made in anodized blue aluminium. Precise and sturdy structure, suitable for scales and automatic weight checking systems in all industrial and commercial applications. Standard version is with approved load cell.
RPLC Series Specifications
|
Options for ATEX Version CCATEX: ATEX certificate for each load cell DCATEXMECH: ATEX declaration for the PLATFORM (for the load cells ATEX declaration see CCATEX-1 code). Option to be offered only if the platform is ordered without the indicator, if so, refer to the chosen weight indicator available certifications |
Options Only Available at Time of Order Connection to the indicator and calibration with CE-M 3000e approval High resolution models for internal factory use |
Available Versions
| Code | l x w x h (mm) | Max (kg) | d (g) | M (g*) | M 2R (g)* | d HR (g)* |
|---|---|---|---|---|---|---|
| RPLC1 | Ø=178, h=45 | 1,5 | 0,2 | 0,5 | 0,2 / 0,5 | 0,05 |
| RPLC3 | Ø=178, h=45 | 3 | 0,5 | 1 | 0,5 / 1 | 0,1 |
| RPLC6 | Ø=178, h=45 | 6 | 1 | 2 | 1 / 2 | 0,2 |
| RPLC15 | Ø=178, h=45 | 15 | 2 | 5 | 2 / 5 | 0,5 |
(*) Divisions obtainable only with the relative options, in combination with Dini Argeo weight indicator.
Parts
Available Versions
| Part # | Description | List Price | Cart / Quote | |
|---|---|---|---|---|
|
RPLC1 | Single cell round platform with 1,5 kg capacity, 0,2 g division, stainless steel loading surface O 178 mm, h= 45 mm, anonized aluminium structure. Cable lenght 1,5 m. |
Consult |
|
|
|
RPLC3 | Single cell round platform with 3 kg capacity, 0,5 g division, stainless steel loading surface O=178 mm, h= 45 mm, anonized aluminium structure. Cable lenght 1,5 m. |
Consult |
|
|
|
RPLC6 | Single cell platform with 6 kg capacity, 1 g division, stainless steel loading surface O 178 mm, h= 45 mm, anonized aluminium structure. Cable lenght 1,5 m. |
Consult |
|
|
|
RPLC15 | Single cell platform with 15 kg capacity, 2 g division, stainless steel loading surface O 178 mm, h= 45 mm, anonized aluminium structure. Cable lenght 1,5 m. |
Consult |
Options
High resolution (d HR)(only at time of order)
| Part # | Description | List Price | Cart / Quote |
|---|---|---|---|
| THR | High Resolution (HR) model. |
Consult |
