Rice Lake RL32022-S Stainless Steel, Single-Ended Beam Load Cell

This stainless steel load cell is the metric version of the RL32018S. Sealed to IP67 standards, load cell capacities range from 300 kg to 5,000 kg. OIML approved and comes with 5 m of cable.

Approvals

Some approval documents are available to view by clicking the icons below.

OIML

WARNING: Cancer and Reproductive Harm California Proposition 65

Full Scale Output:
2.0 mV/V ±0.05%
mV/V/ohm calibration

Output Resistance:
350 (±3) ohm

Input Resistance:
400 (±20) ohm

Material/Finish:
Stainless steel

Temperature:
Compensated:
-14 °F to 104 °F (-10° C to 40° C)
Operating:
0 °F to 150 °F (-18 °C to 65 °C)

Seal Type:
Hermetically sealed, IP69K

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
10 VDC (15 V maximum)

Combined Error:
0.017% full scale

Insulation Resistance:
>5,000 megohm

Deflection at Capacity:
0.2 to 0.4 mm

Cable Length:
5 m

Cable Color Code:
Green +Excitation
Black –Excitation
Red +Signal
White –Signal

Warranty:
Two-year limited

Approvals:
OIML

Rated Capacity A B C D E F G H I J K L M N
kg/mm
300 to 2,000 31.5 15.0 34.6 56.0 31.5 130.0 13.5 18.0 M12 76.2 25.4 15.8 6.5 3.5
3,000 to 5,000 48.0 - 37.0 76.0 41.5 171.5 20.5 18.0 - 75.2 38.1 19.0 - -





Resources / Downloads

Title Download Email
RL32022S Load Cell Catalog Page Download Email

Title Collateral Wizard Request Download Email Category
Load Cell Wiring Guide Request Download Email Load Cells
Load Cell Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Handbook Request Download Email Load Cells|Weigh Modules

Title View Download Email Category
Rice Lake's Load Cell Service, Selection and Speed View Download Email Load Cells

Title Download Email Category
Choosing Load Cells for Tough Applications Download Email Load Cells
Properly Welding on Structures with Load Cells Download Email Load Cells

Parts

Part # Description List Price Cart / Quote
211636 Load Cell, SEB RL32022-S 300kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211637 Load Cell, SEB RL32022-S 500kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211638 Load Cell, SEB RL32022-S 750kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211639 Load Cell, SEB RL32022-S 1000kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211640 Load Cell, SEB RL32022-S 1500kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211641 Load Cell, SEB RL32022-S 2000kg 2mv 350 Ohm 5m Stainless Steel C3 OIML IP69k

List Price: $350.00

211642 Load Cell, SEB RL32022-S 3000kg 2mv 350 Ohm 5m Stainless Steel C3 OIML THRU HOLE IP69k

List Price: $445.00

211643 Load Cell, SEB RL32022-S 5000kg 2mv 350 Ohm 5m Stainless Steel C3 OIML THRU HOLE IP69k

List Price: $445.00
