VPG® Sensortronics® 65016 Alloy Steel, Double-Ended Beam Load Cell

Nickel plated and environmentally protected with stainless steel side plates. Designed for center loading compatibility with RL1600 tank weighing assemblies. Capacities range from 1,000 lb to 75,000 lb. Complete with 25 ft of load cell cable.

Approvals

Some approval documents are available to view by clicking the icons below.

LOGO FM CUS

WARNING: Cancer and Reproductive Harm California Proposition 65

Full Scale Output:
3.0 mV/V nominal

Output Resistance:
699 to 707 ohm

Input Resistance:
686 to 714 ohm

Material/Finish:
High-alloy steel, nickel plated

Temperature:
Operating:
0 °F to 150 °F (-18 °C to 65 °C)

Seal Type:
Environmentally sealed, IP67

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
5 to 10 V DC (15 V maximum)

Nonlinearity:
0.03% full scale

Hysteresis:
0.02% full scale

Insulation Resistance:
5,000 megohm

Cable Length:
25 ft

Cable Diameter:
1,000 to 25,000 lb: 0.200 in
50,000 to 75,000 lb: 0.301 in
Polyurethane jacket

Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal

Warranty:
One-year limited

Approvals:
cFMus



Capacity A1 A2 C D E F CONDUIT ADAPTER
lb/in
1,000 to 5,000 0.50 1.25 1.25 1.25 7.50 6.25 1/4-18 NPT
10,000 to 25,000 0.81 1.99 1.44 1.94 8.75 7.50 1/4-18 NPT
35,000 0.81 2.50 1.50 2.50 8.75 7.50 1/4-18 NPT
50,000 1.31 3.00 2.44 2.94 13.50 11.50 1/2-14 NPT
75,000 1.31 2.44 2.94 13.50 11.50 1/2-14 NPT
75,000lb capacity has a square center



Resources / Downloads

Title Download Email
Sensortronics 65016 Load Cell Catalog Page Download Email

Title Version Revision Download Email Category Archived
Load Cell and Weigh Module Handbook D Download Email Load Cells|Weigh Modules No

Title Collateral Wizard Request Download Email Category
Load Cell and Weigh Module Selection Guide Request Download Email Load Cells|Weigh Modules

Title Download Email Category
Choosing Load Cells for Tough Applications Download Email Load Cells

Parts

Part # Description List Price Cart / Quote
17268 Load Cell,DEB 65016-1K 1000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $583.00

17270 Load Cell,DEB 65016-1.5K 1500lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $583.00

17273 Load Cell,DEB 65016-2.5K 2500lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $583.00

17275 Load Cell,DEB 65016-5K 5000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $583.00

17277 Load Cell,DEB 65016-10K 10,000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $662.00

17279 Load Cell,DEB 65016-15K 15,000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $662.00

17281 Load Cell,DEB 65016-20K 20,000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $662.00

17282 Load Cell,DEB 65016-25K 25,000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $662.00

46498 Load Cell,DEB 65016-35K 35000lb 25ft Sensortronics 3mV/V 700 Ohm WW FM IP67

List Price: $917.00

17284 Load Cell,DEB 65016-50K 50,000lb 25ft 3mv/v 700 Ohm FM IP67 WW SENSTRS

List Price: $1,033.00

25358 Load Cell,DEB 65016-75K 75,000lb 25ft 3mv/v 700 Ohm WW IP67 SENSTRS

List Price: $1,033.00
