Junction Boxes

A junction box is required to properly manage multiple load cell systems. Rice Lake junction boxes are designed to withstand the elements and keep sensitive electronics protected.

What Is a Junction Box?

A junction box, also called a j-box or a summing box, brings multiple load cells together so they can function as a single scale. A junction box houses wire connections from multiple load cells to sum their signals and send the value to a weight indicator. The enclosure provides environmental protection for all of wire connections. A junction box also provides a convenient place to troubleshoot system errors because all load cell connections are in one place.

Filter Results

  • Junction Boxes

Category

Approvals

Feature

Channels

Hdimage(1)

JB4SS TuffSeal® Signal Trim Junction Box

The JB4SS TuffSeal signal trim junction box sums two or four single load cell outputs with the potential to expand and connect other junction boxes.

Hdimage(1)

JB4ES TuffSeal® Excitation Trim Junction Box

The JB4ES TuffSeal excitation trim junction box sums two or four single load cell inputs with the potential to expand and connect other junction boxes.

Hdimage(1)

JB4SP and JB4SPT TuffSeal® Signal Trim Junction Box

The JB4SP and JB4SPT TuffSeal junction box sums two or four single load cell outputs and can be expanded through an expansion port.

Hdimage(1)

JB4EP and JB4EPT TuffSeal® Excitation Trim Junction Box

The JB4EP and JB4EPT TuffSeal junction box sums two or four single load cell outputs and can be expanded through an expansion port.

Hdimage(1)

EL204 Signal Trim Junction Box

The EL204 signal trim junction box is a fit choice for summing two to four single cells in floor, hopper, tank or livestock applications.

Hdimage(1)

EL504 Signal Trim Junction Box

For signal trimming of two or four load cell outputs individually, the EL504 signal trim junction box is perfect for a variety of scales and installations.

1 US JB8SP Open

JB8SP TuffSeal® Signal Trim Junction Box

The JB8SP TuffSeal signal trim junction box effectively seals in sensitive circuitry and resists potentially damaging elements.

Hdimage(1)

JB8SPT TuffSeal® Signal Trim Junction Box

The JB8SPT TuffSeal signal trim junction box with transient protection is the optimal choice for truck, livestock and railroad scales susceptible to potentially destructive outdoor elements.

Hdimage(1)

EL304A Signal Trim Junction Box

The EL304A signal trim junction box has a NEMA Type 4X Fiberglass Reinforced Polyester (FRP) enclosure, providing optimal protection.

Hdimage(1)

JB1010T Signal/Excitation Trim Junction Box

The JB1010T with transient protection provides easy access for trimming up to ten load cells per unit or conveniently adjust multiple cell modules by section.

WEB SC JB1010ST

JB1010ST Signal Trim Junction Box

Specifically for signal trimming, the JB1010ST signal trim junction box provides individual cell and section trim capability as well as transient protection.

Hdimage(1)

iQUBE²® Digital Diagnostic Junction Box

The iQUBE² digital diagnostic junction box provides enhanced features that will redefine expectations for traditional analog to digital technology.
